- Leak before Press® technology
- Male NPT per ASNI/ASME B1.20.1
- Compatible with Pro-Press™ pressing tools
- Approved for underground installation
- Use with hard/soft ASTM B88 K, L and M copper tube
- UNS C27451 brass body
- EPDM O-ring
- ANSI/NSF-61 listed lubrication silicone
- Hot water up to 250 deg F
- Chilled water down to 33 deg F
- Standard/Approvals: ARRA Compliant|cUPC® Listed|IAPMO File No. 4861|6174 and N-4951|NSF/ANSI NSF 61/372|UPC Listed
- Brand: EPCDomestic/Import: DomesticEnd Style: C x MNPTFitting/Connector Type: UnionMaterial: BrassNominal Size: 1-1/2Pressure Rating: 200Series: 8733-4Temperature Rating: 0 to 250
