Uponor TruFLOW™ A2610800 Classic Manifold Assembly With Isolation and Balancing Valves, 3/4 in Inlets x (8) 1-1/4 in Outlets, Brass, Import
Uponor TruFLOW™ Manifold Assembly, Classic, 8 Outlets, 1-1/4 in Outlet, 3/4 in Inlet, 145 psi, 220 deg F, Brass, 12.6 in H x 20.3 in W, Import
Documents
- UNS C3850 Brass
- 1-1/2 in manifold body
- 1.9 Cv loop
- ISO 228-G 3/4 in (R20) manifold body threaded connections
- ISO 228-G 3/4 in (R32) manifold body threaded connections
- 21 gpm fluid flow rate
- TruFLOW classic manifolds are completely assembled and ready for installation right out of the box, use the TruFLOW balancing hex key (A2620002) on the internal balancing valves of the supply manifold, manifold is shipped with the appropriate number of TruFLOW Manifold Actuator Adapters (A2630028)
- Accessories: A2610020: TruFLOW Loop Thermometer, A2610100: TruFLOW Manifold Extension Kit, A3010522: 4-Wire Thermal Actuator, A3020416: 2-Wire Thermal Actuator, A2620021: TruFLOW Classic Manifold Mounting Bracket, single bracket, A2620002: TruFLOW Balancing Hex Key, A2400032: Basic End Cap Gasket, spare part, R32, A2620008: Replacement O-ring for 1-1/4 in BSP Connection, A2620009: Replacement O-ring for TruFLOW Temperature/Flow Meter, A2631250: TruFLOW Manifold S and R Ball Valves, A2631251: Manifold S&R Ball Valves with Temperature Gauges, set of 2, A2631252: Manifold S&R Ball Valves set of 2, A2640027: TruFLOW Visual Flow Meter 0.25 to 2.0 gpm
- 8-loop
- Standard/Approvals: ASTM F877|ESR-1529|NSF RFH|NBC of Canada|IMC|UMC
Uponor TruFLOW™ Manifold Assembly, Classic, 8 Outlets, 1-1/4 in Outlet, 3/4 in Inlet, 145 psi, 220 deg F, Brass, 12.6 in H x 20.3 in W, Import
TruFLOW manifold assemblies with balancing and isolation valves come fully assembled and ready for installation. The assemblies are shipped with the appropriate number of TruFLOW manifold actuator adapters (A2630028). Maximum recommended flow to the manifold is 14 gpm for Jr. (1 in barrel diameter) and 21 gpm for Classic (1-1/4 in barrel diameter).
- Brand: UponorDimensions: 12.6 in H x 20.3 in WDomestic/Import: ImportInlet Size: 3/4Material: BrassNumber of Outlets: 8Outlet Size: 1-1/4Pressure Rating: 145Temperature Rating: 220Type: Classic
