APOLLO LC149-04-1 4" BUTTERFLY VALVE LUG STYLE CI BODY ALUM/BRZ DISC EPDM SEAT LEVER OPERATED

Documents
- The wetted surfaces of this product shall contain no more than 0.25% lead by weighted average
- Buna-N stem seal and glass reinforced epoxy resin bushing
- Black Buna-N seat
- Polished disc edge ensures long seat life, minimal torque
- 1-piece wafer design with flange locating holes in larger sizes
- Through shaft assures positive disc positioning and dependable performance
- Square shaft-to-disc connection provides a robust shaft-to-disc connection without pins or bolts
- Shaft equipped with weather seal to prevent external media from entering the shaft bore
- Isolates body from process media
- Valves are equipped with a stretch-resistant, non-collapsible blow-out proof seat
- Phenolic stiffener ring, resilient seated
- Seat design eliminates the need for flange gaskets
- Designed to dimensions for easy mounting of Apollo actuators and manual operators
- Supports shaft at three locations to enhance shaft alignment and absorb actuator side thrusts
- Precision machined disc edge creates Bubble tight shut-off, primary seal
- Standard/Approvals: API 609|ASTM A126 Class B Body|ASTM B148-C95400 Disc|ASTM A276 Shaft|CRN 0C12102.8CL|Federal Public Law 111-380|MSS SP-67|NSF/ANSI 372 Lead-Free|NSF/ANSI 61 Water Quality|PROP65: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- WARRANTY: 2 Years
- Brand: Apollo™Actuator Type: 10-Position HandleBody Material: Cast IronEnd Style: FlangedNominal Size: 4Port Type: FullPressure Class: 125/150Series: LC149Softgoods Material: EPDMTemperature Rating: -30 to 225Type: Contractor Grade Lug Style
