WATTS® 0825212 77F-DI-FDA-125 Wye Strainer, 4 in Nominal, 12-1/8 in OAL, Flange Connection, Graphite Softgoods, Import
WATTS® Wye Strainer, Series: 77F-DI-FDA-125, 4 in Nominal, 12-1/8 in Overall Length, Flange, 1-1/2 in NPT Blow-Off, Graphite, Cast Iron Body, Epoxy Coated, B Grade, Import
- Wye pattern
- 304 Stainless steel perforated screens
- Flanges conform to american national standards Institute, class 125 (ANSI B16.1) and WW-S-2739 type 2
- Drain/blow-off connection furnished with closure plug
- Flanged
- Standard/Approvals: ASSE Listed|cCSAus Certified|FM Approved|NSF/ANSI 372|UL Listed|ULC Listed|USC Certified
- WARRANTY: 1 year Limited
WATTS® Wye Strainer, Series: 77F-DI-FDA-125, 4 in Nominal, 12-1/8 in Overall Length, Flange, 1-1/2 in NPT Blow-Off, Graphite, Cast Iron Body, Epoxy Coated, B Grade, Import
Series 77F-DI-FDA-125 Cast Iron, Flanged, Wye-Pattern Strainers feature an FDA approved epoxy coating inside and outside and is suitable for potable water and food contact applications. They feature a wye-pattern, Class B cast iron body with Class 125 flanged connections, stainless steel screen, bolted and tapped iron retainer cap with graphite gasket and iron blow-down plug. Maximum Pressure (non-shock): 200 psi at 140 deg F WOG.
- Brand: WATTS®Blow-Off Size: 1-1/2 in NPTConnection Type: FlangedDomestic/Import: ImportFinish: Epoxy CoatedGrade: BNominal Size: 4Overall Length: 12-1/8Series: 77F-DI-FDA-125Body Material: Cast IronSoftgoods Material: Graphite
WATTS® 0825212 77F-DI-FDA-125 Wye Strainer, 4 in Nominal, 12-1/8 in OAL, Flange Connection, Graphite Softgoods, Import
WATTS® Wye Strainer, Series: 77F-DI-FDA-125, 4 in Nominal, 12-1/8 in Overall Length, Flange, 1-1/2 in NPT Blow-Off, Graphite, Cast Iron Body, Epoxy Coated, B Grade, Import
